Measurement methodology for coordinate measuring machines - CMM

Influence of the number of measurement points on shape errors

Omschrijving

Measuring shape errors on coordinate measuring machines is a process that is widely used nowadays due to the ease and speed with which the results of a given characteristic can be obtained. The aim of this work was to establish a rule for determining the minimum number of points to be touched when measuring the roundness of various parts. For the case study, measurements were taken on a part manufactured exclusively for this work, where the initial objective was achieved through calculations and comparisons. Based on the results of the measurements, a rule was defined which consists of touching 1 point/mm of the calculated perimeter, considering the nominal diameter specified in the drawing. The use of the rule allows for greater confidence in the results obtained, as it establishes a standard for circularity measurements in various diameters and a reduction in measurement costs, as the time spent on this process is considerably reduced (72.9% in the case studied) depending on the number of points chosen by the metrologist.
Gratis verzending vanaf
€ 19,95 binnen Nederland
Schrijver
Stoco, Wanderson, de Lima, André, Torrezan, Hamilton
Titel
Measurement methodology for coordinate measuring machines - CMM
Uitgever
Our Knowledge Publishing
Jaar
2024
Taal
Engels
Pagina's
64
EAN
9786207883677
Bindwijze
Paperback
